起源の場所:
中国
ブランド名:
Lishunyuan
証明:
CE
モデル番号:
LY-500HJ
LY-500HJ Semi Automatic Hot Glue Spraying Machine
This machine is very flexible and moveable spray glue machine, which is elaborately organized and developed by our company according to the diversified trend of high-quality box products and the requirements of customers, combining with our years of rich experience in researching and developing box machinery.
Advantages:
Working Process:
Machine Details:
|
|
|
|
1. Standard with hot-melt glue, optional with cold glue. 2. The gluing head is fixed on the gantry robot by servo 3. There are 2 servo motors on the gantry robot respectively for X axis, Y axis and Z axis. |
||
Technical Parameters:
|
Model: |
LY-500HJ |
|
Max size of cover and box |
L900*W600*H120mm |
|
Min size of cover |
L100*W50mm |
|
Machine Speed |
15-25pcs/min |
|
Spray accuracy |
± 0.1mm |
|
Machine Power |
6KW |
|
Air pressure |
0.5-0.7Mpa |
|
Machine weight |
300KG |
|
Machine dimension |
L1400*W1300*H1800mm |
|
Glue type |
Hot melt glue |
Packing and Shipping:
Company Introduction:
Founded in 2001 and situated in Dongguan City, Guangdong Province, LiShunyuan boasts a 20,000-square-meter modern standardized workshop. After 18 years of steady development, the company has built a comprehensive sales and after-sales service network across China, with its products exported to over 40 countries and regions spanning Europe, America, Southeast Asia, South America, the Middle East and Africa.
Innovation stands as LiShunyuan’s core competitive strength. The company holds independent intellectual property rights for its product portfolio, which covers the rigid box machine series and clamshell box machine series. These equipment solutions are widely applied in the production of premium gift boxes, mobile phone packaging boxes, cosmetic boxes, wine and liquor boxes, as well as other high-end boutique packaging boxes.
Upholding the development philosophy of "Customer First, Serve the Globe" and adhering to the development strategy of "Strive for Perfection, Forge New Paths", LiShunyuan is committed to R&D and development of high-performance, high-efficiency new products for the packaging industry, and is at the forefront of driving the rapid advancement of intelligent automation within the sector.
Certification:
Workshop:
Exhibition:
